Diagonal Field of View
- Image Sensor1/2.8″ Progressive CMOS
- DimensionsØ: 146mm / 5.75in, H: 104.3mm / 4.11in with mount plate
Ø: 146mm / 5.75in, H: 99.8mm / 3.93in without mount plate
- Image Resolution2MP / 1920 x 1080
- IR Range15m / 50ft
- Lens TypeFixed
- Day/NightIR-cut filter for day & night function
- Focal Length2.8mm
- Connectivity10/100Mbps RJ-45 cable connector for Network/PoE connection
- Field of View97° Horizontal
- Power InputIEEE 802.3af PoE
- Power Consumption11W
- WeightCamera: 593g / 20.92oz
Mountplate: 143g / 5.04oz
- CertificationsFCC, IK08 vandal resistance, ICES, IEC60950-1, NDAA
- Operating Temperature-10°C - 50°C / 14°F - 122°F
- Included AccessoriesSetup guide, T10 security Torx screwdriver, screw pack, mounting template
- LED IndicatorSystem power and status indicator
- ACC-MNT-2 Mounting Arm Kit
Wall mounted extender arm. Use with Verkada ACC-MNT-1 or ACC-MNT-8 pendant caps.
- ACC-MNT-3 Wall Mounted L-Shaped Bracket Kit
Compact bracket for mounting camera perpendicular to wall.
- ACC-MNT-4 Pole Mount Adapter Kit
Attaches ACC-MNT-2 or ACC-MNT-3 to a pole.
- INJ-POE-PLUS 802.3at PoE Injector
Power over Ethernet (PoE) injector for powering Verkada cameras from a non-PoE enabled network connection
- ACC-MNT-7 Angle Mount Kit
30 degree angled mount for improved field of view.
- ACC-MNT-8 Pendant Cap Mount Kit
Threaded cap that attaches to the rear of Camera. Use with Verkada ACC-MNT-2 mounting arm Built-in 3/4” NPT female and 1.5” NPT male piping connector.
- ACC-MNT-9 Verkada Pole Mount, 2nd Generation
Attaches ACC-MNT-2 or ACC-MNT-3 to a pole. Supports Verkada's Bullet Series.
- ACC-MNT-10 Corner Mount
Versatile bracket for mounting a range of accessories and cameras on corners.
