SV11 Environmental Sensor

Visualize Your Data

Join our upcoming webinar to learn about Verkada’s cloud-based environmental solution and get a FREE Yeti Tumbler.

Improve safety and operations with Verkada Sensors.

Temperature
Sensor: CMOS
Operating Range: -5º C to 50º C (23° F to 122° F)
Typical Accuracy: ± 2° C
Units: º F
Relative Humidity
Sensor: CMOS
Operating Range: 0-80% non-condensing
Typical Accuracy: ± 5%
Units: %
PM 2.5
Sensor: Laser Scattering Optical Sensor
Range: 0 - 1000 μg/m³
Typical Accuracy (0 - 100 μg/m³): ± 10 μg/m³
Typical Accuracy (100 - 1000 μg/m³): ± 10%
Units: μg/m³ (micrograms / cubic meter)
TVOC
Sensor: CMOS
Range: 0-60,000 Index
Typical Accuracy: +/- 15%
Noise
Sensor: Microphone (not recording)
Range: 20 - 120 dB SPL (A-Weighted)
Typical Accuracy: ± 5 dB
Units: dB (decibels)
Air Quality Index
Sensor: Derived from multiple sensors
Range: 0 - 500
Motion
Sensor: Passive Infrared Sensor
Vape Index
Sensor: Proprietary formula derived from multiple sensors
Range: 0 - 100 index
Dimensions & Weight
Dimensions: Ø: 146mm H: 59mm
Weight: 720g / 25.4oz
Power
Power Consumption: 4W
Power Input: IEEE 802.3af PoE
LED Indicator
System power and status indicator
Connectivity
RJ-45 cable connector for Network/PoE connection
Operating Temperature
-5º C to 50º C (23° F to 122° F)
Compliance
FCC, CE, IC, NDAA
Included Accessories
Setup guide, T10 security Torx screwdriver, screw pack, paper mounting template

30-day trial includes sensor and full access to management platform.
