GC31-E Cellular Gateway
Outdoor cellular gateway for deploying Verkada in places that are hard to wire or lack connectivity.
Use cases
Deploy any Verkada device, anywhere
The GC31-E makes it easy to deploy Verkada anywhere with power and cell signal. Feed the GC31-E any power source and it will send both power and data to any Verkada device via PoE.
Deploy any Verkada device, anywhere
The GC31-E makes it easy to deploy Verkada anywhere with power and cell signal. Feed the GC31-E any power source and it will send both power and data to any Verkada device via PoE.
The gateway works with nearly any power source, including AC, light poles, DC, solar, and even vehicles.
Eliminate complexity with the Verkada data plan or bring your own SIM. The Verkada plan offers truly unlimited data, multi-carrier redundancy, and 24/7 support.
With two PoE++ capable outputs that supply up to 60W total, the GC31-E can directly power up to two devices without a switch.
The GC31-E features perpetual PoE outputs, meaning that connected devices stay powered on even when the gateway reboots.
Cloud-managed in Command
Remotely manage gateways via the Command web or mobile app. See all your gateways on a map, remotely run diagnostics, and receive alerts if connectivity is lost.
Find Footage Faster with GPS
You might know where — but not when — an incident occurred. With GPS video search, simply view a vehicle’s route history, click a location, and instantly access all associated footage.
Dual SIM/auto SIM failover
(2 x LAN and 1 x WAN/LAN configurable)
60W total power budget
IEEE 802.3bt Type 4 PoE++ 90W
12-36V DC Terminal Block
Note: Power accessories sold separately
(GPS, GLONASS, and Galileo)
19W below -25°C / -13°F
Note: Does not include connected devices
- Main Unit:
Length: 243mm / 9.6in
Width: 148mm / 5.9in
Height: 33mm / 1.3in - Antenna:
Ø: 25mm / 1.0in
L: 179mm / 7.1in
1Cellular carriers and operators throughout the world may only require telecom industry certifications such as PTCRB to operate on their network. Some carriers require additional testing and approval, beyond telecom certifications. A carrier listed in the approvals section means Verkada completed additional testing and acquired technical approval for that given carrier. Any carrier not listed may not require additional testing or approval beyond telecom industry certifications to operate on their network.
Accessories
IP66-rated PoE++ injector for powering the GC31-E in harsh environments. The GC31-E can be mounted directly on the injector.
PoE++ injector for powering the GC31-E. Place the injector indoors or within a NEMA enclosure.
AC/DC barrel jack adapter for powering the GC31-E. Place the adapter indoors or within a NEMA enclosure.
Power the GC31-E by tapping into the electrical circuit of a streetlight. The power tap connects directly to AC and provides PoE.
Directional LTE antenna for improving signal strength on the GC31-E.
