Dome

Durable and versatile, built to withstand high-traffic areas.
Get Trial Camera

D30 Dome

Designed for any indoor environment, this general purpose camera is ready to withstand high-traffic areas. The D30 Dome includes built-in audio and powerful night vision, capable of delivering high quality security at any time of the day (or night).
  • 3 MP
    Image Resolution
  • 3 X
    Optical Zoom
  • 30 M
    IR Range

Product Specifications

  • Image Sensor
    1/2.8″ Progressive CMOS
  • Image Resolution
    2048x1536 (3MP)
  • Lens Type
    Varifocal
  • Focal Length
    f = 3 - 9 mm
  • Aperture
    F1.2 - F2.3
  • Auto-iris
    P-iris
  • Field of View
    41° - 86° Horizontal
    31° - 64° Vertical
    51° - 113° Diagonal
  • Shutter Speed
    1/5 sec. to 1/16000 sec.
  • Day/Night
    IR-cut filter for day & night function
  • IR Range
    98 feet / 30 meters
  • LED Indicator
    System power and status indicator
  • Connectors
    RJ-45 cable connector for Network/PoE connection
  • Uplink Usage (low-bandwidth mode)
    ~20 kbps
  • Bandwidth Usage (View Mode)
    ~300 kbps (standard)/~1,000 kbps (low latency)
  • Power Input
    IEEE 802.3af PoE
  • Power Consumption
    11W
  • Dimensions
    Ø 145mm x 106mm / 5.7 inches x 4.2 inches
  • Weight
    22.2oz / 503g
  • Certifications
    IK08 vandal resistance, FCC, ICES, IEC60950-1
  • Operating Temperature
    -14°F - 122°F (-10°C - 50°C)
  • Humidity
    90%
  • Included Accessories
    Setup guide, T10 security Torx screwdriver, screw pack, mounting template
Download PDF

Accessory List

  • ACC-MNT-1 Pendant Cap Mounting Adapter Kit

    Threaded cap that attaches to the rear of Camera. Use with Verkada ACC-MNT-2 mounting arm Built-in 3/4” NPT female and 1.5” NPT male piping connector.

  • ACC-MNT-2 Mounting Arm Kit

    Wall mounted extender arm. Use with Verkada ACC-MNT-1 pendant cap

  • ACC-MNT-3 Wall Mounted L-Shaped Bracket Kit

    Compact bracket for mounting camera perpendicular to wall

  • ACC-MNT-4 Pole Mount Adapter Kit

    Attaches ACC-MNT-2 or ACC-MNT-3 to a pole

  • INJ-POE-PLUS 802.3at PoE Injector

    Power over Ethernet (PoE) injector for powering Verkada cameras from a non-PoE enabled network connection

A Modern Camera Solution

Features that strengthen enterprise security and streamline surveillance management.
  • 01

    Centralized Management

    Gain visibility of all cameras with a single, easy-to-use platform.

  • 02

    Smart Features

    Everything you need to easily manage and monitor footage.

  • 03

    Remote Access

    Securely access cameras from any location, across all devices.

  • Floor Plan View

    Manage cameras across any number of locations and levels with floor plan view, and pin cameras to precise locations.

  • People & Car Detection

    With activity-based indexing, Verkada logs object-specific activities and alerts users of unusual motion in frame.

  • Share Feeds Instantly

    Share live links and get footage in the right hands without having to open ports or download supporting software.

Simple Setup

Step
01

Place camera over mount plate screws and twist counter-clockwise. Tighten screws with a Phillips screwdriver.

Step
02

Connect the camera to a Power over Ethernet (PoE) port on your network.

Step
03

Adjust your camera lens to the desired viewing angle.

Step
04

Replace the camera cover and secure it using the provided T10 Torx security screwdriver.

Full Install Guide
