CF83-E Fisheye
Expansive 180° Coverage with Detailed 12.5MP Resolution
Vertical: 180°
Diagonal: 180°
0 lux with IR Illuminators on
Card: MicroSD, SDXC
Standard quality (SQ): Up to 600 Kbps
Extended temperature range: IEEE 802.3at Type 2 PoE+
Without IR: 42.5 - 57V, 0.22-0.17A, 9.5W
Extended temperature range: 42.5 - 57V, 0.59A - 0.44A, 24.8W
RFC 2326
Max concurrent streams: 2
Audio support: No
Mount plate: 196g / 6.9oz
Ø: 155mm / 6.10in, H: 69.2mm / 2.72in without mount plate
1All our cameras record in "adaptive quality", capturing both standard and high quality streams. Standard quality (SQ) video is stored up to the amount of retention specified by the customer. The amount of high quality video stored on the camera will depend on the amount of motion detected by the camera over time. To learn more, visit our website: https://docs.verkada.com/docs/adaptive-quality-recording-whitepaper.pdf
2Extended temperature range includes operating temperatures below -10°C / 14°F and assumes IR will be enabled.
3Frame rate can be adjusted by support.
4Trajectory analysis is supported in four-way split, panoramic, and ePTZ circle mode
Accessories
ACC-MNT-ANGLE-1
Angle Mount
Mounts Fisheye and Dome cameras 30 degrees from wall for improved field of view.
ACC-CAM-SHIELD-1
Camera Weather Shield
Weather shield for protecting the camera against external elements.
ACC-MNT-ARM-1
Arm Mount
Wall mounted extender arm with built in 1.5” female NPT thread.
ACC-MNT-PEND-1
Standard Pendant Cap
Threaded cap features built in 3/4” female NPT and 1.5” male NPT threads.
ACC-MNT-ARM-1
Arm Mount
Wall mounted extender arm with built in 1.5” female NPT thread.
ACC-MNT-UPEND-1
Umbrella Pendant Cap
Threaded cap features built in 3/4” female NPT and 1.5” male NPT thread with extra protection from weathering.
ACC-MNT-CJBOX-1
Circle Junction Box
Junction box for mounting dome and fisheye cameras
ACC-MNT-CLIP-1
Tile Clip
For mounting indoor Dome, Mini and Fisheye cameras to commercial ceiling tile rails from 9/16" to 15/16" wide without the requirement to drill. Customers may still wish to drill a hole to properly conceal the cable.
ACC-MNT-PEND-1
Standard Pendant Cap
Threaded cap features built in 3/4” female NPT and 1.5” male NPT threads.
ACC-MNT-POLE-1
Pole Mount
For mounting cameras to circular poles 2" to 6" in diameter.
ACC-MNT-ANGLE-1
Angle Mount
Mounts Fisheye and Dome cameras 30 degrees from wall for improved field of view.
ACC-CAM-SHIELD-1
Camera Weather Shield
Weather shield for protecting the camera against external elements.
ACC-MNT-POLE-1
Pole Mount
For mounting cameras to circular poles 2" to 6" in diameter.
ACC-MNT-ARM-1
Arm Mount
Wall mounted extender arm with built in 1.5” female NPT thread.
ACC-MNT-PEND-1
Standard Pendant Cap
Threaded cap features built in 3/4” female NPT and 1.5” male NPT threads.
ACC-MNT-POLE-1
Pole Mount
For mounting cameras to circular poles 2" to 6" in diameter.
ACC-MNT-ARM-1
Arm Mount
Wall mounted extender arm with built in 1.5” female NPT thread.
ACC-MNT-UPEND-1
Umbrella Pendant Cap
Threaded cap features built in 3/4” female NPT and 1.5” male NPT thread with extra protection from weathering.
ACC-MNT-CORNER-1
Corner Mount
Mount for installing cameras and accessories to external corners.
ACC-MNT-ANGLE-1
Angle Mount
Mounts Fisheye and Dome cameras 30 degrees from wall for improved field of view.
ACC-CAM-SHIELD-1
Camera Weather Shield
Weather shield for protecting the camera against external elements.
ACC-MNT-CORNER-1
Corner Mount
Mount for installing cameras and accessories to external corners.
ACC-MNT-ARM-1
Arm Mount
Wall mounted extender arm with built in 1.5” female NPT thread.
ACC-MNT-PEND-1
Standard Pendant Cap
Threaded cap features built in 3/4” female NPT and 1.5” male NPT threads.
ACC-MNT-CORNER-1
Corner Mount
Mount for installing cameras and accessories to external corners.
ACC-MNT-ARM-1
Arm Mount
Wall mounted extender arm with built in 1.5” female NPT thread.
ACC-MNT-UPEND-1
Umbrella Pendant Cap
Threaded cap features built in 3/4” female NPT and 1.5” male NPT thread with extra protection from weathering.
