CM41-E Outdoor Mini Dome

Durable, discreet mini dome built for outdoor and high-traffic environments.

Product Specifications

Image Sensor
1/2.8" Progressive CMOS
Dimensions
Diameter: 121 mm / 4.78 in
Height: 72 mm / 2.83 in
Image Resolution
5MP (2688 x 1944)
IR Range
15m / 50 ft
Lens Type
Fixed
Day/Night
IR-cut filter for day & night function
Focus
Fixed
Focal Length
2.8mm
Aperture
F1.6
Connectivity
10/100Mbps RJ-45 cable connector for Network/PoE connection
Field of View
97° Horizontal
71° Vertical
128° Diagonal
Power Input
IEEE 802.3af PoE
Iris
Fixed
Power Consumption
12W
Weight
544 g / 19.2 oz
Certifications
FCC, IP67, IP6K9K, IK10 vandal resistance, IEC 60950, IEC 62368, NDAA, EN 50155 Railway compliance, EN 45545 Railway Fire compliance, EN 50121 Railway EMC compliance
Operating Temperature
-40°C - 55°C / -40°F - 122°F
Humidity
90%
Included Accessories
Quick installation guide, T10 security torx screwdriver, mounting screws, mounting template, desiccant bags, cable sealing components
LED Indicator
System power and status indicator

INJ-POE-PLUS 802.3at PoE Injector
Power over Ethernet (PoE) injector for powering Verkada cameras from a non-PoE enabled network connection
ACC-MNT-6 Mini Camera Junction Box Kit
For mounting a Mini camera to a standard junction box. Includes a plastic cover for aesthetic appeal.

30-day trial includes camera and full access to management platform.
