CM41-E Outdoor Mini Dome

CM41-E Outdoor Mini Dome

Durable, discreet mini dome built for outdoor and high-traffic environments.
  • 5 MP
    Image Resolution
  • 128°
    Diagonal Field of View
  • IP67
    and IK10 Rated
  • 15 M
    IR Range

Product Specifications

  • Image Sensor
    1/2.8" Progressive CMOS
  • Dimensions
    Diameter: 121 mm / 4.78 in
    Height: 72 mm / 2.83 in
  • Image Resolution
    5MP (2688 x 1944)
  • IR Range
    15m / 50 ft
  • Lens Type
    Fixed
  • Day/Night
    IR-cut filter for day & night function
  • Focus
    Fixed
  • Focal Length
    2.8mm
  • Aperture
    F1.6
  • Connectivity
    10/100Mbps RJ-45 cable connector for Network/PoE connection
  • Field of View
    97° Horizontal
    71° Vertical
    128° Diagonal
  • Power Input
    IEEE 802.3af PoE
  • Iris
    Fixed
  • Power Consumption
    12W
  • Weight
    544 g / 19.2 oz
  • Certifications
    FCC, IP67, IP6K9K, IK10 vandal resistance, IEC 60950, IEC 62368, NDAA, EN 50155 Railway compliance, EN 45545 Railway Fire compliance, EN 50121 Railway EMC compliance
  • Operating Temperature
    -40°C - 55°C / -40°F - 122°F
  • Humidity
    90%
  • Included Accessories
    Quick installation guide, T10 security torx screwdriver, mounting screws, mounting template, desiccant bags, cable sealing components
  • LED Indicator
    System power and status indicator

Accessory List

  • INJ-POE-PLUS 802.3at PoE Injector

    Power over Ethernet (PoE) injector for powering Verkada cameras from a non-PoE enabled network connection

  • ACC-MNT-6 Mini Camera Junction Box Kit

    For mounting a Mini camera to a standard junction box. Includes a plastic cover for aesthetic appeal.
